GIGABYTE B650 A Elite AX ICE 1.1 emaplaat AMD AM5 / B650 / DDR5 / 4×DIMM / ATX (B650AELITEAXICE)

The Gigabyte B650 A Elite AX ICE 1.1 motherboard is designed for AMD Ryzen processors using the AM5 socket and built on the B650 chipset. It features a robust power delivery system, four DDR5 slots, high-speed PCIe 4.0 M.2 storage, wireless connectivity (Wi-Fi + Bluetooth), and reinforced PCIe slots. The ATX form factor offers extensive expandability for gaming and professional systems. SpecificationsModel: Gigabyte B650 A Elite AX ICE 1.1Device type: MotherboardCPU socket: AMD AM5Chipset: AMD B650Form factor: ATX MemoryType: DDR5Slots: 4× DIMMMode: Dual ChannelMax capacity: 192 GBProfile support: AMD EXPO / XMPSupported speeds: high DDR5 OC frequencies PowerVRM: multi-phase designVRM cooling: large heatsinks, thermal padsPower connectors: 8-pin + 8-pin CPU, 24-pin ATX Expansion1× PCIe 4.0 x16 (reinforced)1× PCIe 3.0 x16 (x4 electrical)1× PCIe 3.0 x1 Storage3× M.2 PCIe 4.0 x4 (2280)4× SATA 6 Gb/sRAID: 0 / 1 / 10 WirelessWi-Fi 6 or newerBluetooth supported Networking & audioLAN: 2.5 GbEAudio: HD AudioAudio ports: standard 3.5 mm Rear I/OUSB 3.2 Gen2 Type-CUSB 3.2 Gen2USB 3.2 Gen1USB 2.0HDMIRJ-45 LANAudio jacks On-board connectorsARGB/RGB headersFan headers: CPU_FAN, PUMP, SYS_FANUSB headers for front panel Other featuresPCIe slot reinforcementBIOS update without CPUWindows 11 supportTPM support Board dimensions: 30.5 cm × 24.4 cm Physical parametersWeight: 1.20 kgGross weight: 2.00 kgPackage dimensionsLength, m: 0.3300Height, m: 0.2800Width, m: 0.0700
